Knife Making Hydraulic Press for Sale
Forging machines have been made by Anyang Forging Press Company since 1956. The forging press sizes have ranged from 800 Ton to 8000 Ton and are found in many automotive and industrial forging companies around the world. In 2017, we made the decision to utilize their knowledge of presses and machining capability to make a series of presses aimed at blacksmiths, bladesmiths, and the small industrial sector. Sizes will range from 25 Ton (Metric) to 150 Ton model.
Contact US
Get Price
Share:
Previous:
Blacksmith Small Forging Press for Sale
Content
| item | Y04-25 | Y04-50 | Y04-150 | |
| Normal force | 25 T | 50 T | 150 T | |
| Working speed | ≤20mm/s | ≤20mm/s | ≤15mm/s | |
| Stroke speed | down | ≥40mm/s | ≥50mm/s | ≥150mm/s |
| up | ≥60mm/s | ≥55mm/s | ≥100mm/s | |
| Maximum working area： | 300mm×400mm | 380mm×400mm | 600mm×600mm | |
| (L × H) | ||||
| Dimension of worktable ： | 300mm×200mm | 380mm×300mm | 600mm×400mm | |
| (L × W) | ||||
| worktable height | 900±20mm | 900±20mm | 700±20mm | |
| Hydraulic Oil Volume | 240L | 450L | 450L | |
| (Anti-wear hydraulic oil YB-N46) | ||||
| Motor Power | 4KW | 7.5KW | 30KW | |
| Outsize | 1200mm× | 1500mm× | 2850mm× | |
| (L×W×H) | 765mm× | 1110mm× | 1600mm× | |
| 2080mm | 2140mm | 4080mm | ||
| Weight | 860KG | 1855KG | 9000KG | |
***************************************************************************************************************************************************************
If you are interested in it, pls contact me.
Felicia
felicia@anyanghammer.com
WhatsApp/WeChat: +86-16692292870
