Hydraulic Open Die Forging Press (Y13)

Power pneumatic forging hammer is a self-contained pneumatic power hammer. The design is based on the tried and true design of old European pneumatic hammers, many of which are still in use today. With a self-contained power hammer, you don’t need an external air supply or high pressure hose.

The forging hammer belongs to a kind of free forging equipment. It is a forging machine that uses the kinetic energy generated by the falling motion of the hammer to continuously hit the workpiece blank to produce plastic deformation.

Pneumatic Hammer, a kind of free forging machine. Air Hammer Forging Machine The compression cylinder compresses the air and sends it into the working cylinder through the distribution valve, pushing the piston together with the hammer head to move up and down for hammering.

Hydraulic free forging press is mainly used for metal free forging, but also for load-bearing die forging. It has the functions of rapid forging, normal forging, pressure holding, etc., and meets various forging technical requirements such as upsetting, drawing, perforation, saddle forging, bending, etc. , partial forging, etc.

A forging press (sometimes simply called a press) is a machine that uses a vertical plunger to gradually apply greater force to a die. Forging presses do not repeatedly strike exposed parts like a power forging hammer—forging presses slowly shape a piece of metal and create uniform plastic deformation across the material.

Power hammers are mechanically driven forging tools that use hydraulic oil to lift the hammer and strike, helping the blacksmith to complete more advanced blacksmithing projects faster.

C41 series pneumatic hammers are widely used in general free forgings, such as drawing, upsetting, punching, chiseling, forging welding, bending, twisting, etc. It is also used for open and closed forging with pillow die.

This is a small hydraulic press built by Anyang Forging Press. It’s slow, but if you’re patient enough, it can actually forge a steel forging well.

The full hydraulic free forging hammer refers to the free forging hammer whose strike and return stroke of the hammer head are hydraulically driven. The principle of the system is that the lower chamber of the hammer rod piston is usually connected with high-pressure oil, and the strike and return stroke are realized by controlling the oil pressure of the upper chamber of the piston. The full hydraulic free forging hammer has the advantages of sufficient energy, fast frequency, low failure rate, and can realize hanging hammer at any position. It is suitable for producing various types of free forgings.

​The internal parts of Anyang pneumatic forging hammer are forged steel and precision machined. There are no internal rubber air hoses to deteriorate over time. The drive belts are external to the machine for easy adjustment and away from harmful oil.

At a competitive price, we offer quality Pneumatic Forging Hammers made in China. The Forging Hammer in the picture is a 400kg Pneumatic Forging Hammer we manufacture for an Indian customer.

Pneumatic hammer forging machine is a free forging equipment, the whole machine is suitable for small manufacturing and repair industries.

Electro-hydraulic hammer is a new type of forging equipment that is energy-saving and environmentally friendly. The guide of the hammer head is changed to “X” guide rail, which can adjust the guide rail clearance to a very low level, greatly improving the guiding accuracy of the electro-hydraulic hammer, improving the quality of forgings, extending the Hammer life.

It includes a general hydraulic free forging press and a special ring rolling blanking hydraulic press. The general hydraulic free forging press is mainly used in metal open die forging, also used for bolster die forging,with functions of fast forging, normal forging and pressure keeping, etc, satisfying various forging technical requirements, such as upsetting, drawing out, piercing, saddle forging, bending, offset forging, etc.

At present, the all-hydraulic electro-hydraulic hammer has been applied to various specifications and series of die forging hammers and free forging hammers. Practice has proved that the all-hydraulic electro-hydraulic hammer is an ideal upgrade product for the hydraulic-pneumatic hammer.
