D51 Series Vertical Ring Rolling Machine Working Principle and Application

Diameter control – Axial ring rolling machine, also known as reaming machine, is a numerical control equipment that integrates mechanics, electricity, hydraulics and instruments. It is a very effective method to process high-quality seamless rings with this equipment, and it has many excellent processes. Features; mainly used for rolling bearing rings, ring gears, flanges, wheel hubs, thin-walled barrels, wind power flanges, high-diameter flanges and other forgings

Vertical ring rolling (reaming) machine is a special equipment for ring blank hot rolling and reaming process. The equipment has the characteristics of high degree of automation, small size, light weight, strong rigidity, sensitive and reliable operation, etc. It is an essential equipment in the axle industry.

The ring rolling machine can produce continuous local deformation of ring forgings, and then realize the processing technology of reducing wall thickness, expanding diameter, and forming cross-section contours. The ring rolling machine is suitable for producing annular mechanical parts of various shapes and sizes, such as bearing rings, ring gears, flanges, wheel hubs, thin-walled cylindrical parts, wind power flanges, high-diameter flanges, and other seamless annular forgings.

Ring rolling / ring rolling / reaming is a plastic processing process that uses a ring rolling machine to produce continuous local plastic deformation of the ring, thereby reducing wall thickness, expanding diameter, and forming cross-sectional contours.

High-quality ring rolling machine/iron ring forming machine is widely used in machinery, automobiles, trains, ships, petrochemicals, aerospace, atomic energy, wind energy Bearing outer rings, gears
Blanks, pipe flanges, butt welding flanges.

Ring rolling machines are divided into vertical and horizontal types according to the form of the frame and the location of the ring parts. Most small and medium-sized ring rolling machines adopt the inclined vertical type for the convenience of operation.

Ring rolling machine are divided into the radial rolling and radial-axial rolling(D53K series,CNC controlled).

The D51 ring rolling machine rolls profiled and rectangular rings with high precision and cost-effectiveness, the machine concept is particularly easy to maintain and user friendly.

Anyang Forging Company, established in 1956, is a high-tech enterprise specializing in the research, development, design and manufacture of ring rolling machines. All products of Anyang Forging Company have passed ISO9001 international quality system certification and CE certification. The model of the ring rolling machine in the picture is D51-500, which is produced for an Indian customer.
