Blacksmith Power Hammer for Sale Australia
This is a self-contained hammer that doesn’t require an additional compressor air supply, has a more solid casting frame integrated air channel, and a longer ram design that prevents the top die from retracting into the cylinder. It has more power, better control, is quieter, and is easy to maintain.
Contact US
Get Price
Share:
Previous:
Anyang Power Hammer for Blacksmith
Content
Model | Unit | C41-9 | C41-15 | C41-25 | C41-40 | C41-55 | C41-75 | C41-110 | |||
Structure | One piece | One piece | One piece | Two pieces | One piece | One piece | Two pieces | One piece | One piece | ||
Weight of falling parts | kg | 9 | 15 | 25 | 40 | 40 | 55 | 75 | 75 | 110 | |
Hitting energy | kJ | 0.09 | 0.16 | 0.27 | 0.53 | 0.53 | 0.7 | 1 | 1 | 1.98 | |
Hitting frequency | min-1 | 245 | 300 | 250 | 245 | 245 | 230 | 210 | 210 | 180 | |
Height of the working area | mm | 135 | 160 | 240 | 245 | 245 | 270 | 297 | 297 | 355 | |
Depth of throat | mm | 120 | 140 | 200 | 235 | 235 | 270 | 280 | 280 | 400 | |
Working Piece | Square | mm | 25×25 | 30×30 | 40×40 | 52×52 | 52×52 | 60×60 | 65×65 | 65×65 | 110×110 |
Round | mm | Φ30 | Φ35 | Φ48 | Φ68 | Φ68 | Φ75 | Φ85 | Φ85 | Φ120 | |
Motor | Model | Y90L-4-B3 | Y100L1-4-B3 | Y132S-6-B3 | Y112M-4 | Y132M1-6-B3 | Y160M-6 | Y132M-4 | Y132M-4 | Y180L- | |
6-B3 | |||||||||||
Power | Kw | 1.5 | 2.2 | 3 | 4 | 4 | 7.5 | 7.5 | 7.5 | 15 | |
Weight | Include base | kg | 392 | 462 | 970 | 710 | 1226 | 1626 | 2300 | 2500 | 3300 |
Anvil block | kg | 420 | 720 | ||||||||
Outside size | mm | 1090 | 1150 | 1435 | 1200 | 1615 | 1830 | 1570 | 1570 | 1910 | |
500 | 555 | 685 | 765 | 765 | 845 | 930 | 930 | 1070 | |||
1440 | 1515 | 1725 | 1365 | 1785 | 1950 | 1875 | 1875 | 2382 |
***************************************************************************************************************************************************************
We can provide 9-2000kg Power Forging Hammers / Air Forging Hammer / Pneumatic Forging Hammer.
If you are interested in it, pls contact me.
